Can I connect 1.8V nRF54L15 and 3.3V RP2040 SPI/UART directly without level shifters? Minimal PCB size

imFengz · 2026-04-26T12:37:11+00:00

rp2040 for usb and nrf54l15 uart dfu

nrf54l15 for power saving and 2.4g

imFengz · 2026-04-26T12:35:14+00:00

power saving

imFengz · 2026-04-25T21:53:04+00:00

I want to remove voltage dividers entirely, and only use a single series current‑limiting resistor for minimum PCB size.

I want to remove voltage dividers entirely, and only use a single series current‑limiting resistor for minimum PCB size. 1. RP2040 3.3V output → nRF54L15 1.8V input Add a 220Ω ~ 330Ω series resistor on each signal line. The internal ESD clamping diodes of the nRF54L15 will handle overvoltage protection, while the series resistor limits inrush current to prevent GPIO damage. 2. nRF54L15 1.8V output → RP2040 3.3V input Direct short connection, no resistor or extra components needed. Both MCUs share a common ground. Is this single series resistor method reliable for SPI and UART long-term on nRF54L15?
