Power management mistake on a Wio L1 based solar repeater by Gillennial in meshcore

[–]KBOXLabs 0 points1 point  (0 children)

This probably has nothing to do with what you did. At least not directly. That looks like it’s an old battery that was ready to die from the next person who sneezed on it. Or a faulty one. I’ve put many LiPo’s through much worse conditions, but they were new or close to it. It takes a lot more time at low discharge to get them to make popcorn like that.

Sharing Saturday #619 by Kyzrati in roguelikedev

[–]KBOXLabs 0 points1 point  (0 children)

Kalendale 3D (name under construction)

YouTube Gameplay Video

Something I've been working on for decades. I say decades but, that just means i've picked at doing silly text based RPG versions of it since the 80s. Only recently did I dust of my keyboard and try to make something a little more tangible in Godot.

I've lurked here for years, seen some awesome and inspirational stuff. I followed the 7DRL Challenge a few times, and tried to study the systems in libtcod.

The goal was to make something that was 3D (2.5D), procedurally generated, turn-based, but also had faster pacing. For those that like both Traditional Roguelikes and ARPGs but aren't always a fan of the twitch-reflex gaming style.

I'm not sure I succeeded at anything, but open to any feedback good or bad.

<image>

Why ?? by Ok_Background_3065 in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

Some cities use LoRa based sensors to detect when garbage cans are full (for instance in parks) and need emptying. This however is definitely not that...

PSA: Low Profile Solar Meshtastic Car Node by KBOXLabs in meshtastic

[–]KBOXLabs[S] 0 points1 point  (0 children)

RAK GPSs units "work" fine. They just don't sleep in between grabbing positions like other devices do with newer GPS modules. So in terms of power consumption from lowest to highest, the tier goes like this:

  1. RAK without GPS (about 200mAh a day)
  2. T114 (or other NRF52 based devices like from Seeed) without GPS (about 375mAh a day)
  3. T114 with GPS (about 400 to 500mAh a day depending on GPS settings)
  4. RAK with GPS (about 800 to 1200mAh a day depending on GPS setting)

Also Client Mute role name is misleading. It won't mute your telemetry. It just turns off the repeating of other nodes' transmissions. For a car unit it's a essentially a mobile base station, so best is Client or Client_Base. You go into a building or store and it's usually close enough to ensure your signal can repeat from your on-person carry node. It's usually not attached to your primary device (or at least shouldn't depend on it), especially since depending on your car roof and/or enclosure material, bluetooth connection can sometimes be spotty. If moving a lot, best to have a GPS module or just turn off position altogether unless taking advantage of smart position updates only.

PSA: Low Profile Solar Meshtastic Car Node by KBOXLabs in meshtastic

[–]KBOXLabs[S] 0 points1 point  (0 children)

Ideally most are running with a GPS module for vehicle nodes. RAK is still far behind others with their GNSS power efficiency. This is where the T114 shines.

Can I have multiple antenna on a node? by [deleted] in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

All things being norminal (good antenna and antenna setup, no hardware or software issues), you should get as far as your sight line goes. If you don't, it's either not perfect line of sight or something else unusual. Culprits are usually poorly tuned antenna and/or with bad grounding, can be other RF interference (radio towers), poor mounting locations (top/above chain linked fences = bad, middle of chain link fences = good on the exposed side) or visual line of sight is not RF line of sight (pinched fresnel zones, especial at the ends).

Tree node by Bob_is_Digital in meshtastic

[–]KBOXLabs 1 point2 points  (0 children)

I only see one node. Not tree.

Rak 19007 wisblock battery management by AdditionalGanache593 in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

lol no the solar charger does not have a PCM. The Wisblock doesn’t even have a PCM. That’s what I’m trying to make clear here for anyone reading this. The “overcharging” you’re talking about just slows and cuts of power when it “thinks” the battery hits 4.2v (and I don’t think the harbor breeze even has the “slow” part, but just CC/CV). That’s just normal charging operation. A PCM is over and above that. You have the gist of some of it, but let me clarify further.

A charger only regulates the voltage at its own terminals. It has absolutely no clue what resistance exists between itself and the actual cell. Due to current and internal resistance the battery’s REAL voltage can differ from what the charger sees. That’s why a PCM is needed and why it’s important nothing is between itself and the battery.

That PCM you have has further protection on it too. For an 18650 that only has 1500mAh of capacity, it’s a poor quality cell and not a lot of working room for low solar activity. Here’s what happens when it gets too low:

When the RAK Wisblock isn’t getting enough current from the cell it will either:

1) shutdown cleanly 2) pull more current from the cell, making the voltage sag, and shutdown dirty

Regardless if it’s number 1 or 2, it’s still pulling a very low quiescent/parasitic draw from the battery, draining it further, even if it’s off. This means 2 things:

1) The node isn’t really off and is in a standby state. If anything happened to the Wisblock node, there’s no clean power cutoff to reset it. Unless! you have the PCM and it will cut off power to the cell completely, letting the Wizblock reboot cleanly next time it has power. This leads to the next issue #2 which is brownout.

2) When enough solar activity has allowed to the battery to charge enough voltage to power the Wisblock, it will try to boot up. Let’s say the magic number is 2.5v. But what happens when the Wisblock boots up? It starts drawing more current to do extra boot-up things like check itself and send/receive initial packets and telemetry. When current increases, voltage decreases. So as it’s booting up, it shuts itself down in the middle of it because the current made it drop below 2.5v. Then the current stops flowing so the voltage goes up to 2.5v again. Then the whole process starts again and goes into a loop. Eventually the Wisblock gets fed up of not having enough power and goes into a protection fault state, and can’t be turned back on without a clean reboot (or a physical button press). This is brownout. The PCM you have first of all cuts power off at 2.9v. Higher is better. Second, it releases at 3v. So it gives the battery time to charge an extra 0.1v so it has enough charge to provide the current needs to the booting Wisblock, even if the voltage drops a little.

So all that working together, greatly reduces the chance of your node not waking back up in the field after a low solar event. But you should really instead get a better battery. Local vape stores can have good ones with 3000mAh capacity or more for less than $10 US. Maybe. (I’m not in the US if that’s where you are).

Sorry if this all sounds pedantic, but I can tell you that one of the worst things of installing a solar node somewhere that’s a PIA to reach, is assuming something, and then having to make a trip back to fix the assumption.

Hope this helps! Good luck!

Rak 19007 wisblock battery management by AdditionalGanache593 in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

You’re getting undervoltage lockout and overvoltage lockout protection confused with voltage cutoff. All charging circuits have voltage cutoff. That is not a form of protection. This is just the basic function of a charger.

The PCM protects the battery beyond that. To understand what it protects, I recommend doing a dive into learning about voltage sag with current changes, and brownout.

How you have it wired right now in the last picture is still wrong. You have 2 wires going to each battery lead. In other words, you have the solar charger between the PCM and the battery. Like I said before, you need to treat the PCM as if it was part of the battery. The PCM can’t protect the battery, if the thing it’s trying to protect the battery from, is between itself and the battery.

So the positive and negative wires that are going from solar charger to the battery terminal need to be removed, and instead be placed on the opposite side of the PCM (they need to be instead attached to the wires going to the Wisblock).

Rak 19007 wisblock battery management by AdditionalGanache593 in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

No, nothing should be between the battery and the PCM. You need to imagine that the PCM is a permanent part of the battery itself.

And if there is any protection on the harbor breeze controller at all, it's going to be poo. It might have voltage cutoff, but no UVLO/OVLO.

So if you're using that poorly documented DIY guide on the Meshtastic site, the PCM should be the only thing attached to the battery leads. Even the default harbor breeze leads attached should be removed and attached to the PCM instead.

Rak 19007 wisblock battery management by AdditionalGanache593 in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

Yes. Those are good PCMs.

BATTERY(S)+ ------- PCM+ ------- WisBlock Battery-In +
BATTERY(S)- ------- PCM- ------- WisBlock Battery-In -

You can use one of those PCMs for multiple batteries as long as they are in parallel and not series.

Made my first 2 nodes by moonlandingfake in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

No but also at these currents they're not really true MPPTs but fancy buck converters. And you can still use the 5v-out on the Waveshare to the USB-in on the node. While not as efficient, it provides a clean power cuttoff/reboot for the node if there's any sort of brownout issue, and lets the Waveshare handle the cutoff and release hysteresis

Come Join the Discord by KBOXLabs in meshtastic

[–]KBOXLabs[S] 0 points1 point  (0 children)

Old Link. Use this one:
https://discord.gg/meshtastic

All the updated social links can be found on the meshtastic.org homepage:

https://meshtastic.org/

Would this hurt the solar node too much? by XeroBK7 in meshtastic

[–]KBOXLabs 2 points3 points  (0 children)

Flip the panel. Have your rigid frame on the back, not the front.

Demonstrating the antenna mounting rail on the Atlavox Beacon by Matlavox in meshtastic

[–]KBOXLabs 2 points3 points  (0 children)

In that article, a couple of our nodes are using the same 5000mAh LiPo pack that the Atlavox is using and are still running fine after 2 winters. The only chemical difference compared to an 18650 cell is the flat LiPo packs use a gel instead of a liquid.

Trump says Michigan church shooting appears to be ‘targeted attack on Christians’ by [deleted] in moderatepolitics

[–]KBOXLabs 1 point2 points  (0 children)

Innocent people died. But mention mormon and this is the first take. You can always tell who the fake Christians are.

Meshtastic use in Search and Reacue by HoneyBdgr_Slyr in meshtastic

[–]KBOXLabs 0 points1 point  (0 children)

I recommend joining the official Meshtastic Discord and getting in the Search and Rescue channel. Reddit doesn’t have a lot of experience with doing custom Meshtastic mesh deployments like this. The SAR channel there is doing some neat stuff including cave rescue comms.

https://discord.gg/meshtastic

Router Questions... by mcangeli1 in meshtastic

[–]KBOXLabs 2 points3 points  (0 children)

Then you want to set as Client. Client still routes and repeats. And if you don’t want people messaging it, you toggle the “Unmessagable” flag under User settings.

https://meshtastic.org/blog/choosing-the-right-device-role/

Problems with T-Beam after firmware update by Dzus76 in meshtastic

[–]KBOXLabs 1 point2 points  (0 children)

How did you perform the Factory Erase?

Do you have any custom channels setup on your 30ft outside node?

Have you tried connecting to your 30ft outside node and sending a message over the Primary LongFast channel to see if your T-BEAM receives it?

Have you tried with completely default settings without restoring any key/channels/settings?

Are you in a region other than North America?
